Channels
1
Pipe Material
PC Clear (UL94 V-0)
Shield Material
PC+ABS White (UL94 V-0)
ESD Protection
< 8 kV
Operating Temperature
−40 °C ~ +90 °C
Pitch
N/A
LED Suggestion
<1206
TAZ12
TAZ11 is a compact PCB-mounted light guide designed to transmit LED signals to a visible indicator surface. Its press-fit mounting and diffused output provide stable alignment and clear status indication in electronic equipment and control interfaces.
PCB Mounting Hole
Ø2.35-2.40mm
Mounting Method
Press-Fit
Mounting Type
PCB Mount
Lens Dimension
Ø3.00 × 4.00 mm
Lens Shape
Round
Alignment
Horizontal
Lens Optics
Flat
Lens Finish
Diffused
