Channels
2
Pipe Material
PC Clear (UL94 V-0)
Shield Material
PC+ABS White (UL94 V-0)
ESD Protection
< 8 kV
Operating Temperature
−40 °C ~ +90 °C
Pitch
5.08mm
LED Suggestion
LxWxH<4.60x2.80x2.20mm
TAA12
TAA12 is a horizontal dual-channel PCB-mounted light guide designed to transmit LED signals from the PCB to visible indicator points on the device surface. Its press-fit mounting ensures stable installation and precise alignment, while the diffused round lenses provide clear and uniform status indication. With a 5.08 mm pitch, it is suitable for PLC modules, control panels, and industrial electronic equipment.
PCB Mounting Hole
Ø2.30mm
Mounting Method
Press-Fit
Mounting Type
PCB Mount
Lens Dimension
Ø3.00 × 4.50 mm
Lens Shape
Round
Alignment
Horizontal
Lens Optics
Flat
Lens Finish
Diffused
