Channels
6
Pipe Material
PC Clear (UL94 V-0)
Shield Material
PA66 black Ul94 V0
ESD Protection
< 8 kV
Operating Temperature
−40 °C ~ +90 °C
Pitch
N/A
LED Suggestion
LxWxH<10.0x4.70x2.80mm
TAD18
TAD18 is a single-row PCB light guide designed for multi-channel LED indication. The structure integrates 6 light outputs in one module, providing clear and organized status display for industrial electronics and control systems. A black PA66 shielding structure helps isolate the optical channels and reduce light interference, ensuring clear and reliable signal indication.
PCB Mounting Hole
ø2.50mm
Mounting Method
Press-Fit
Mounting Type
PCB Mount
Lens Dimension
ø6.30×4.00mm
Lens Shape
Round
Alignment
Horizontal
Lens Optics
Flat
Lens Finish
Diffused
